F - Series

BN-F25D

Technical Specifications

  • Weight: 16.5 kg
  • Power Consumption: 250 Watt
  • Dimension: 720mm x 460mm x 95mm
  • Input Voltage: 110 – 240 Vac, 50/60 Hz
  • Maximum Working Environment Humidity: 85%
  • Maximum Working Environment Temperature: -20° to 60°C

BN-F15D

Technical Specifications

  • Weight: 10 kg
  • Dimension: 630mm x 290mm x 95mm
  • Input Voltage: 110 – 240 Vac, 50/60 Hz
  • Maximum Power Consumption: 150 Watt
  • Maximum Working Environment Humidity: 85%
  • Maximum Working Environment Temperature: -20° to 60°C

BN-F15

Technical Specifications

  • Weight: 8.5 kg
  • Dimension: 580mm x 290mm x 95mm
  • Input Voltage: 110 – 240 Vac, 50/60HZ
  • Estimated LED Lifetime: 50,000 Hours
  • Maximum Power Consumption: 150 Watt
  • Maximum Working Environment Humidity: 85%
  • Maximum Working Environment Temperature: -20˚C to 60˚C

BN-F12RGB

Technical Specifications

  • Weight: 7 Kg
  • Input Voltage: 110 – 240 Vac, 50/60HZ
  • Dimension: 400mm x 185mm x 95mm
  • Estimated LED Lifetime: 50,000 Hours
  • Maximum Power Consumption: 360 Watt
  • Maximum Working Environment Humidity: 85%
  • Maximum Working Environment Temperature: -20˚C to 60˚C

BN-F12DK2

Technical Specifications

  • Weight: 8.6 Kg
  • Estimated LED Lifetime: 50,000 Hours
  • Input Voltage: 110 – 240 Vac, 50/60HZ
  • Dimension: 460mm x 290mm x 95mm
  • Maximum Power Consumption: 120 Watt
  • Maximum Working Environment Humidity: 85%
  • Working Environment Temperature: -20˚C to 60˚C

BN-F12K1

Technical Specifications

  • Weight: 7 Kg
  • Estimated LED Lifetime: 50,000 Hours
  • Input Voltage: 110 – 240 Vac, 50/60HZ
  • Dimension: 400mm x 185mm x 95mm
  • Maximum Power Consumption: 120 Watt
  • Maximum Working Environment Humidity: 85%
  • Working Environment Temperature: -20˚C to 60˚C

BN-F12032

Technical Specifications

  • Weight: 5.6 kg
  • Estimated LED Lifetime: 50,000 Hours
  • Input Voltage: 110 – 240 Vac, 50/60 Hz
  • Dimension: 150mm x 505mm x 175mm
  • Maximum Power Consumption: 120 Watt
  • Maximum Working Environment Humidity: 85%
  • Working Environment Temperature: -20˚C to 60˚C
